Marvell has introduced the industry’s first 2nm custom SRAM, engineered to support custom XPUs powering AI data centers. The memory innovation delivers improved performance per mm² while reducing power and die area demands.
What is Covered in this Article:
- Marvell introduced the industry’s first 2nm custom SRAM, targeting AI infrastructure and custom XPU designs
- The new memory delivers up to 6 gigabits and achieves the industry’s highest bandwidth per mm²
- SRAM enables up to 15% die area recovery and up to 66% lower standby power
- Marvell aims to expand its presence in the $55.4 billion custom compute TAM in CY 2028, with 18 active sockets, >10 customers, and >50 opportunities in the pipeline
- The company’s broader strategy focuses on custom silicon offerings for performance, power, and cost optimization
The News: Marvell Technology (NASDAQ: MRVL) has rolled out the industry’s first 2nm custom Static Random Access Memory (SRAM), built to boost the performance of custom XPUs and AI-driven systems in cloud data centers. The SRAM combines Marvell’s own circuitry and software with core SRAM design and cutting-edge 2nm process tech.
This new memory delivers up to 6 gigabits of fast storage and uses up to 66% less standby power than standard on-chip SRAM. It can also help recover up to 15% of chip die space in 2nm designs, giving developers more room to optimize for compute power, size, or cost.
Marvell Expands Custom AI Portfolio With Launch of 2nm Custom SRAM
Analyst Take: Marvell’s 2nm custom SRAM marks a step in its push to improve AI hardware through custom infrastructure. With boosts in both performance and efficiency, this move supports Marvell’s ongoing effort to refine memory layouts for high-performance compute systems.
Greater Memory Density in a Smaller Footprint
This custom SRAM lets chipmakers reclaim up to 15% of die space in 2nm designs, making room for other cores or critical features. It offers top bandwidth per square millimeter, which is crucial for AI due to the need for faster data in more compact spaces. Compared to other dense memory setups, Marvell’s SRAM delivers 17x more bandwidth density while using half the area for the same throughput. This opens the door to smaller, more powerful chips that don’t sacrifice speed or performance. It’s a strong base for building XPUs tuned to specific workloads.
Power Efficiency at High Operating Frequency
Built to run at speeds up to 3.75 GHz, the 2nm SRAM uses up to 66% less standby power than typical on-chip memory at similar sizes. That combo of speed and efficiency is ideal for power-hungry AI clusters where every watt counts. As energy limits and thermal continues to be a key challenge for data center buildouts, savings like these help reduce heat and improve overall system efficiency. That’s also a plus for customers looking to cut long-term operating costs, since lower idle power adds up across massive deployments. Marvell’s efficient design helps balance power and performance in custom setups.
Addressing a $55.4 billion Market Opportunity
Marvell’s new SRAM supports its growing footprint in the $55.4 billion custom compute market in CY 2028, which includes $40.8 billion from custom XPUs and $14.6 billion from related components. The attach side is growing at 90% annually, while XPUs are rising at 47% CAGR through 2028. Marvell already has 18 design wins with major and emerging hyperscalers, aiming to grab 20% of this market over time. With over 50 potential projects in the pipeline totaling $75 billion+ in value, this SRAM will be a key piece of many upcoming deals. Its flexibility and strong performance make it a competitive edge in new bids.
Part of a Broader Custom Silicon Playbook
This SRAM launch builds on Marvell’s earlier work in HBM and CXL tech – both aimed at boosting bandwidth and system integration. The new memory fits into a broader stack that includes electrical and optical serializer/deserializers (SerDes), chip-to-chip links, and advanced packaging technologies, all designed with specific customer needs in mind. Tying SRAM into this mix ensures a common design approach and smoother integration. Marvell is creating a full set of IP designed to lift system performance across compute and memory. With SRAM now added, the company has another strong card in its next-gen custom silicon lineup.
What to Watch:
- The scalability and adoption rate of Marvell’s 2nm SRAM across existing custom sockets
- Design wins involving the new SRAM from top hyperscalers and emerging AI players
- Execution against Marvell’s 20% market share target in the $55.4 billion custom compute TAM
- Integration of SRAM with other Marvell IPs like HBM, SerDes, and co-packaged components
See the complete press release on Marvell’s launch of the industry’s first 2nm custom SRAM on the Marvell website.
